صنایع بالا دستی نفت و گاز >> رشته حفاری- Drilling String >>
کد کالا : 167

Drill Pipe 3 1/2"- 13.30lb/ft- 6105(G105-S135)- R2-Conn:NC3813- TC2000

Drill Pipe 3 1/2"- 13.30lb/ft- 6105(G105-S135)- R2-Conn:NC3813- TC2000

قیمت : 0 (تومان)
مبلغ قابل پرداخت : 0   (تومان)
˄˅

نمایش محصولات

بررسی تخصصی و اجمالی

Drill pipe 3 1/2 inch, 13.3 lb/ft, API 5DP drill pipe, oilfield drilling tools, NC38 connection, IEU drill pipe, TC2000 internal coating, 6105 grade drill pipe, R2 range, oil & gas equipment, high strength drill string

The 3½" Drill Pipe 13.30 lb/ft 6105 R2 (IEU) offers unmatched strength, precision, and corrosion resistance. Equipped with an NC38 premium connection and TC2000 internal coating, it’s engineered for superior torque transmission, durability, and reliability in the most demanding oil, gas, and geothermal drilling environments.

:Applications

  • Oil & gas well drilling (onshore and offshore)

    Directional and horizontal drilling operations

    Geothermal and mining exploration wells

    Suitable for high-pressure, high-temperature (HPHT) environments

    :Key Advantages

    High tensile, torsional, and bending strength as per API 5DP

    TC2000 internal coating ensures excellent corrosion resistance

    NC38 premium threaded connection for torque stability and leak-proof sealing

    Standard R2 length for easy rig handling and transport

    Precision-machined joints for maximum operational safety

    IEU upset design increases fatigue resistance and durability

مشخصات فنی

مشخصات فنی (Technical Specifications)

مشخصه مقدار / توضیح Specification Description
قطر بیرونی لوله (OD) 3½ اینچ Outside Diameter (OD) 3.5 inch
وزن واحد طول 13.30 پوند بر فوت Weight 13.30 lb/ft
گرید فولاد 6105 Steel Grade 6105 (High-strength alloy steel)
طول هر شاخه 31 فوت (حدود 9.45 متر) Range / Length R2 / 31 ft
نوع Upset IEU (Internal & External Upset) Upset Type IEU
قطر بیرونی Tool Joint 4¾ اینچ Tool Joint OD 4 3/4 inch
قطر داخلی Tool Joint 2 7/16 اینچ Tool Joint ID 2 7/16 inch
فضای گشتاور (Tong Space) پین: 9" / باکس: 11½" Tong Space Pin: 9" / Box: 11½"
نوع پوشش داخلی TC2000 ضد خوردگی Internal Coating TC2000 (Anti-corrosion coating)
نوع اتصال (Connection) NC3813I Connection Type NC3813I (Equivalent to NC38 / API IF)
زاویه اتصال Tool Joint 18 درجه Shoulder Angle 18°
استاندارد تولید مطابقت با API SPEC 5DP Standard API 5DP Compliant
سازوکار رزوه API Rotary Shoulder Connection Thread Type NC38
جنس لوله فولاد آلیاژی عملیات‌حرارتی‌شده Material Heat-treated alloy steel

سایز

"1/2 3
